• Rear axle, 3.42 ratio
• Pickup bed
• GVWR, 7000 lbs. (3175 kg)
• Push Button Start
• Automatic Stop/Start
• Auto-locking rear differential
• Transfer case, single speed, electronic Autotrac with push button control (4WD models only)
• Suspension Package, High Capacity
• Four wheel drive
• Alternator, 220 amps
• Battery, heavy-duty 730 cold-cranking amps/80 Amp-hr, maintenance-free with rundown protection and retained accessory power
• Frame, fully-boxed, hydroformed front section
• Recovery hooks, front, frame-mounted, Black
• Cargo tie downs (12), fixed
• Steering, Electric Power Steering (EPS) assist, rack-and-pinion
• Brakes, 4-wheel antilock, 4-wheel disc with DURALIFE rotors
• Capless Fuel Fill
• Exhaust, single outlet
• Exhaust, aluminized stainless-steel muffler and tailpipe

• Wheels, 20" x 9" (50.8 cm x 22.9 cm) 6-spoke High gloss Black painted aluminum
• Tires, 275/60R20 all-season, blackwall
• Tire, spare 255/80R17SL all-season, blackwall
• Wheel, 17" x 8" (43.2 cm x 20.3 cm) full-size, steel spare
• Tire carrier lock keyed cylinder lock that utilizes same key as ignition and door
• Bumper, front, body-color lower
• Bumper, rear body-color with corner steps
• CornerStep, rear bumper
• Grille (Body color header with gloss black mesh grille insert bars.)
• Headlamps, LED projectors with Fade-on/Fade-off animation, LED turn signals and Daytime Running Lamps
• IntelliBeam, automatic high beam on/off (Included and only available with (PDI) GMC Pro Safety.)
• Fog lamps, LED
• Taillamps, LED LED signature taillight and Fade-on/Fade-off animation, incandescent stop, turn and reverse light
• Mirrors, outside heated power-adjustable
• Glass, deep-tinted
• Lamps, cargo area, cab mounted integrated with center high mount stop lamp, with switch in bank on left side of steering wheel
• LED Cargo Area Lighting located in cargo bed activated with switch on center switch bank or key fob
• Tailgate, GMC MultiPro Tailgate with six functional load/access features
• Tailgate, gate function manual with EZ Lift includes power lock and release, includes hitch area light
• Tailgate and bed rail protection caps, top
• Door handles, body-color

• Audio System, 13.4" diagonal Premium GMC Infotainment System with Google built in apps such as navigation and voice assistance, includes color touch-screen, multi-touch display, AM/FM stereo Bluetooth® streaming audio for music and most phones; featuring wireless Android Auto and Apple CarPlay capability for compatible phones
• SiriusXM
• SiriusXM with 360L Equipped with SiriusXM with 360L. Enjoy a trial subscription of the Platinum Plan for the full 360L experience, with a greater variety of SiriusXM content, a more personalized experience and easier navigation. With the Platinum Plan you can also enjoy your favorites everywhere you go, with the SiriusXM app, online and at home on compatible connected devices. (IMPORTANT: The SiriusXM radio trial package is not provided on vehicles that are ordered for Fleet Daily Rental ("FDR") use. If you decide to continue service after your trial, the subscription plan you choose will automatically renew thereafter and you will be charged according to your chosen payment method at then-current rates. Fees and taxes apply. See the SiriusXM Customer Agreement at www.siriusxm.com for complete terms and how to cancel. All fees, content, features, and availability are subject to change. GM connected vehicle services vary by vehicle model and require active service plan, working electrical system, cell reception and GPS signal. See onstar.com for details and limitations.)
• Audio system feature, 6-speaker system
• Bluetooth® for phone connectivity to vehicle infotainment system
• Wireless, Apple CarPlay / Wireless Android Auto
• Steering wheel audio controls
• Wi-Fi Hotspot capable (Terms and limitations apply. See onstar.com or dealer for details.)

• Seats, front 40/20/40 split-bench with covered armrest storage and under-seat storage (lockable)
• Seat trim, Cloth
• Seat adjuster, driver 10-way power including lumbar
• Seat adjuster, passenger 4-way manual
• Seating, heated driver and front outboard passenger
• Floor covering, color-keyed carpeting (Includes (B32) front floor mats and (B33) rear floor mats on Crew Cab and Double Cab models.)
• Floor mats, rubberized-vinyl front
• Floor mats, rubberized-vinyl rear
• Steering column, manual Tilt-Wheel and telescoping
• Steering wheel, wrapped
• Steering wheel, heated
• Driver Information Center, enhanced, 12.3" diagonal reconfigurable multicolor digital display
• GMC Premium information Display- 13.4" diagonal Multicolor I touch screen
• Compass, located in instrument cluster
• Exterior Temperature Display, located in radio display
• Brake lining wear indicator
• Windows, power front, drivers express up/down
• Window, power front, passenger express down
• Windows, power rear, express down
• Door locks, power
• Keyless Open and Start includes remote keyless entry
• Remote vehicle starter system
• Cruise control, steering wheel-mounted
• Theft-deterrent system, unauthorized entry
• USB Ports, 2, Charge/Data ports located on instrument panel
• Power outlet, interior power outlet, 120-volt (400 watts shared with (KC9) bed mounted power outlet)
• USB ports, (2) charge-only, rear
• Power outlet, bed mounted, 120-volt (400 watts shared with (KI4) interior power outlet)
• Air conditioning, dual-zone automatic climate control
• Air vents, rear
• Defogger, rear-window electric
• Mirror, inside rearview, manual tilt
• Assist handles front A-pillar mounted for driver and passenger, rear B-pillar mounted
• GMC Connected Access capable (Subject to terms. See onstar.com or dealer for details.)

• Automatic Emergency Braking (Included and only available with (PDI) GMC Pro Safety.)
• Front Pedestrian Braking (Included and only available with (PDI) GMC Pro Safety.)
• StabiliTrak, stability control system with Proactive Roll Avoidance and traction control, includes electronic trailer sway control and hill start assist
• Daytime Running Lamps, LED signature lighting
• Airbags, Dual-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front and rear outboard seating positions; Includes front outboard Passenger Sensing System for frontal outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• OnStar and GMC Connected Services capable (Terms and limitations apply. See onstar.com or dealer for details.)
• Hitch Guidance
• HD Rear Vision Camera
• Following Distance Indicator (Included and only available with (PDI) GMC Pro Safety.)
• Forward Collision Alert (Included and only available with (PDI) GMC Pro Safety.)
• Lane Keep Assist with Lane Departure Warning (Included and only available with (PDI) GMC Pro Safety.)
• Seat Belt Adjustable Guide Loops, front row only
• Buckle to Drive (Included and only available with (PDI) GMC Pro Safety.)
• Tire Pressure Monitor System, auto learn includes Tire Fill Alert (does not apply to spare tire)
• Rear Seat Reminder
• Rear seat belt warning
• 3 Years of OnStar Remote Access. The OnStar Remote Access Plan gives you simplified remote control of your properly equipped vehicle and unlocks a variety of great features in your myGMC mobile app. See dealer for details. (OnStar Remote Access Plan does not include emergency or security services. Fleet customers will get Fleet Remote Access through OnStar Vehicle Insights. See onstar.com for details and limitations. Available on select Apple and Android devices. Service availability, features and functionality vary by vehicle, device, and the plan you are enrolled in. Terms apply. Device data connection required.)

ENGINE, TURBOMAX

• (310 hp [231 kW] @ 5600 rpm
• 430 lb-ft of torque [583 Nm] @ 3000 rpm) (STD)

• 4-Wheel Disc Brakes
• A/C
• ABS
• Adjustable Steering Wheel
• Aluminum Wheels
• AM/FM Stereo
• AUDIO SYSTEM 13.4 DIAGONAL PREMIUM GMC INFOTAINMENT SYSTEM WITH GOOGLE BUILT IN APPS SUCH AS NAVIGATION AND VOICE ASSISTANCE INCLUDES COLOR TOUCH-SCREEN MULTI-TOUCH DISPLAY AM/FM STEREO Bluetooth® streaming audio for music and most phones; featuring wireless Android Auto and Apple CarPlay capability for compatible phones (STD)
• Automatic Highbeams
• Auxiliary Audio Input
• Back-Up Camera
• Bluetooth® Connection
• Climate Control
• Cloth Seats
• Cruise Control
• Daytime Running Lights
• Driver Adjustable Lumbar
• Driver Air Bag
• ELEVATION PREFERRED EQUIPMENT GROUP includes standard equipment
• ENGINE TURBOMAX (310 hp [231 kW] @ 5600 rpm 430 lb-ft of torque [583 Nm] @ 3000 rpm) (STD)
• Floor Mats
• Fog Lamps
• Four Wheel Drive
• Front Collision Mitigation
• Front Collision Warning
• Front Head Air Bag
• Front Side Air Bag
• Heated Front Seat(s)
• Heated Mirrors
• Heated Steering Wheel
• JET BLACK CLOTH SEAT TRIM
• Keyless Entry
• Keyless Start
• Lane Departure Warning
• Lane Keeping Assist
• LED Headlights
• Locking/Limited Slip Differential
• MP3 Capability
• Multi-Zone A/C
• Navigation System
• ONYX BLACK
• Passenger Air Bag
• Passenger Air Bag Sensor
• Power Door Locks
• Power Driver Seat
• Power Mirror(s)
• Power Steering
• Power Windows
• Privacy Glass
• REAR AXLE 3.42 RATIO
• Rear Defrost
• Rear Head Air Bag
• Remote Engine Start
• Requires Subscription
• Satellite Radio
• SEATS FRONT 40/20/40 SPLIT-BENCH with covered armrest storage and under-seat storage (lockable) (STD)
• Security System
• Smart Device Integration
• Split Bench Seat
• Stability Control
• STEERING COLUMN LOCK ELECTRICAL (Beginning with start of production through July 31 2023 vehicles will be forced to include (R7N) Not Equipped with Steering Column Lock which removes Steering Column Lock. See dealer for details. Vehicles built on or after July 31 2023 will include (N06) Steering Column Lock.)
• Steering Wheel Audio Controls
• TAILGATE STANDARD
• Telematics
• Tire Pressure Monitor
• TIRES 275/60R20SL ALL-TERRAIN BLACKWALL
• Tires - Front All-Season
• Tires - Rear All-Season
• Tow Hitch
• Tow Hooks
• Traction Control
• TRANSMISSION 8-SPEED AUTOMATIC (COLUMN SHIFTER) ELECTRONICALLY CONTROLLED with overdrive and tow/haul mode. Includes Cruise Grade Braking and Powertrain Grade Braking (STD)
• Turbocharged
• WHEELS 20 X 9 (50.8 CM X 22.9 CM) 6-SPOKE HIGH GLOSS BLACK PAINTED ALUMINUM (STD)
• WiFi Hotspot

• Mileage
• Fuel Economy Est-Combined (MPG): 18
• EPA Fuel Economy Est - City (MPG): 17
• EPA Fuel Economy Est - Hwy (MPG): 20
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 730
• Maximum Alternator Capacity (amps): 220
• Cooling System
• Total Cooling System Capacity (qts): - TBD -
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3800
• Gross Axle Wt Rating - Rear (lbs): 3800
• Curb Weight - Front (lbs): 2846
• Curb Weight - Rear (lbs): 1982
• Gross Vehicle Weight Rating Cap (lbs): 7000
• Gross Combined Wt Rating (lbs): 14500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 8900
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 890
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 8600
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 2150
• Maximum Trailering Capacity (lbs): 8900
• Suspension
• Suspension Type - Front: Independent
• Suspension Type - Rear: Solid Axle
• Spring Capacity - Front (lbs): 3800
• Spring Capacity - Rear (lbs): 3850
• Axle Type - Front: - TBD -
• Axle Type - Rear: - TBD -
• Axle Capacity - Front (lbs): 3800
• Axle Capacity - Rear (lbs): 3800
• Axle Ratio (:1) - Front: 3.42
• Axle Ratio (:1) - Rear: 3.42
• Shock Absorber Diameter - Front (mm): - TBD -
• Shock Absorber Diameter - Rear (mm): - TBD -
• Stabilizer Bar Diameter - Front (in): 1.30
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13.5 x 1.18
• Rear Brake Rotor Diam x Thickness (in): 13.6 x 0.79
• Tires
• Front Tire Order Code: QAB
• Rear Tire Order Code: QAB
• Spare Tire Order Code: QAQ
• Front Tire Size: 275/60R20
• Rear Tire Size: 275/60R20
• Spare Tire Size: 255/80R17SL
• Front Tire Capacity (lbs): 3800
• Rear Tire Capacity (lbs): 3800
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: N/A
• Revolutions/Mile @ 45 mph - Rear: N/A
• Revolutions/Mile @ 45 mph - Spare: N/A
• Wheels
• Front Wheel Size (in): 20 x 9
• Rear Wheel Size (in): 20 x 9
• Spare Wheel Size (in): 17 x 8
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Electric Rack & Pinion
• Steering Ratio (:1), On Center: - TBD -
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 46.9
• Turning Diameter - Wall to Wall (ft): N/A
• Frame
• Frame Type: Hydroformed
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 24
• Fuel Tank Location: - TBD -
• Exterior Dimensions
• Wheelbase (in): 147.43
• Length, Overall (in): 231.92
• Width, Max w/o mirrors (in): 81.24
• Height, Overall (in): 75.51
• Overhang, Front (in): - TBD -
• Overhang, Rear w/o bumper (in): - TBD -
• Front Bumper to Back of Cab (in): - TBD -
• Cab to Axle (in): - TBD -
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): - TBD -
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 8.08
• Ground Clearance, Rear (in): 8.08
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 69.92
• Cargo Box Width @ Top, Rear (in): - TBD -
• Cargo Box Width @ Floor (in): 71.4
• Cargo Box Width @ Wheelhousings (in): 50.63
• Cargo Box (Area) Height (in): 22.4
• Tailgate Width (in): - TBD -
• Cargo Volume (ft³): 62.9
• Ext'd Cab Cargo Volume (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 43.03
• Front Leg Room (in): 44.53
• Front Shoulder Room (in): 66.02
• Front Hip Room (in): 61.18
• Second Head Room (in): 40.12
• Second Leg Room (in): 43.4
• Second Shoulder Room (in): 65.16
• Second Hip Room (in): 60.24
• Summary
• Vehicle Name: GMC Sierra 1500
• Body Style: Crew Cab Pickup
• Body Code: E63
• Emissions
• EPA Greenhouse Gas Score: 4
• Tons/yr of CO2 Emissions @ 15K mi/year: 9.9
